Product Description
This 2020 Kobelco SK75 midi excavator offers reliable performance for contractors seeking proven Japanese engineering. Currently located in Guangxi, China, this machine delivers excellent versatility for utility work, residential construction, and landscaping applications.
The SK75 is recognized for its compact footprint combined with productive digging capability, making it ideal for confined jobsites where space is limited. Kobelco's reputation for fuel efficiency and reduced operating costs makes this model a sound investment for growing fleets.
- Year of Manufacture: 2020
- Brand: Kobelco
- Model: SK75
- Location: Guangxi, China
- Category: Midi Excavator
Suitable for export or regional deployment. Contact us for detailed inspection reports, shipping arrangements, and pricing information tailored to your operational requirements.
| Specifications | Value |
|---|---|
| No. | 1162650 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
