Product Description
Engineered for precision and operator confidence, this 2016 Komatsu PC200-8N1 delivers reliable performance in demanding excavation environments. Powered by a Komatsu SAA6D107E-1-A engine producing 110 kW at 2000 rpm, this 20-ton excavator combines robust hydraulic power with refined control systems. The spacious cabin provides exceptional visibility across the 9875mm maximum digging radius, allowing operators to maintain situational awareness throughout extended shifts.
Stability remains paramount with a 19,500 kg working weight distributed across 600mm track plates, achieving optimal ground pressure of 44.1 kPa. Hydraulic responsiveness is immediate, with working circuit pressure reaching 34.8 Mpa for precise bucket and arm movements. The 0.8 m³ bucket generates 149 kN digging force, while the 2900mm rod delivers 108 kN for challenging material extraction.
- Enhanced cabin ergonomics with intuitive control layout
- Low-vibration operation reduces operator fatigue
- Wide front windshield maximizes worksite visibility
- Smooth 12.4 rpm rotation speed for controlled positioning
- Water-cooled 6-cylinder engine ensures consistent performance
Located in Jiangsu, this joint-
| Specifications | Value |
|---|---|
| No. | 1010225 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19500 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2900 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D107E-1-A |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.69 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 108 |
| Travel speed (km/h) | 5.5/4.1/3.0 |
| Rotary hydraulic motor type | Fixed displacement axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Working Hydraulic Circuit (Mpa) | 34.8 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 135 |
| Hydraulic System (L) | 232 |
| Total transport length (mm) | 9425 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3040 |
| Minimum turning radius of front working device (mm) | 3040 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9875 |
| Maximum digging depth (mm) | 6620 |
| Maximum excavation height (mm) | 10000 |
| Maximum unloading height (mm) | 1110 |
| Maximum excavation radius of stop surface (mm) | 9700 |
