Product Description
Discover the reliability and performance of a 2020 Komatsu PC400-7, now available in Guangdong, China. This used heavy machine comes equipped with a demolition arm and standard attachments, making it a versatile addition to any construction or demolition project. Known for its durability and efficiency, this excavator is in good condition, ensuring that it is ready to meet the demands of your next job. Ideal for businesses looking for a robust and well-maintained piece of equipment, the Komatsu PC400-7 offers the perfect blend of power and precision.
- Year: 2020
- Brand: Komatsu
- Model: PC400-7
- Location: Guangdong, China
- Includes: Demolition arm and standard attachments
- Condition: Good
| Specifications | Value |
|---|---|
| No. | 1120820 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 41400 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 3380 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | SAA6D125E-3 |
| Rated power (kw/rpm) | 246/1850 |
| Displacement (L) | 11.04 |
| Ground specific pressure (Kpa) | 77.5 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 275 |
| Rod digging force (kN) | 214 |
| Maximum tractive force (kN) | 329 |
| Travel speed (km/h) | 5.5/3.0 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Working Hydraulic Circuit (Mpa) | 37.3 |
| Pilot Oil Circuit (MPa) | 3.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1–160*1270*110mm |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1–185*1820*120mm |
| Boom cylinders - Number × diameter × stroke (mm) | 2–160*1570*110mm |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 248 |
| Engine Oil changes (L) | 38 |
| Coolant (L) | 34.2 |
| Total transport length (mm) | 11940 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3635 |
| Full cab height (mm) | 3265 |
| Counterweight ground clearance (mm) | 1320 |
| Minimum ground clearance (mm) | 555 |
| Back end turning radius (mm) | 3645 |
| Onboard width (mm) | 2995 |
| Total track length (mm) | 5025 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4020 |
| Maximum digging radius (mm) | 12025 |
| Maximum digging depth (mm) | 7820 |
| Maximum excavation height (mm) | 10915 |
| Maximum unloading height (mm) | 7565 |
| Maximum vertical digging depth (mm) | 6870 |
