2020 Komatsu PC400-8

1/9
Buy Komatsu PC400-8 Used Excavator / 1
Buy Komatsu PC400-8 Used Excavator / 2
Buy Komatsu PC400-8 Used Excavator / 3
Buy Komatsu PC400-8 Used Excavator / 4
Buy Komatsu PC400-8 Used Excavator / 5
Buy Komatsu PC400-8 Used Excavator / 6
Buy Komatsu PC400-8 Used Excavator / 7
Buy Komatsu PC400-8 Used Excavator / 8
Buy Komatsu PC400-8 Used Excavator / 9

Product Description

This 2020 Komatsu PC400-8 excavator represents a well-maintained single-owner machine from Fujian, China. With over 17,000 operating hours, this proven workhorse demonstrates the reliability Komatsu is known for in demanding applications. The PC400-8 features a robust hydraulic system and efficient fuel consumption, making it suitable for heavy excavation, material handling, and site development projects.

Key highlights:

  • Single previous owner with documented service history
  • Equipped with hydraulic breaker attachment for versatility
  • 40-ton class performance with proven durability
  • Standard bucket configuration included
  • Currently located in Fujian Province, ready for inspection

This PC400-8 offers contractors and fleet operators a dependable platform for mid-to-large scale earthmoving operations. The machine has been maintained in working condition and is available for immediate deployment.

SpecificationsValue
No.1085409
Tonnage (tons)40
Working weight (kg)42100
Bucket capacity (m³)1.9
Boom length (mm)7060
Rod length (mm)3380
Country of originJining, Shandong Province
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeKomatsu SAA6D1125E-5
Rated power (kw/rpm)257/1900
Cooling modewater-cooling
Cylinder diameter × stroke (mm)125 x 150
Number of cylinders (PCS)6
Displacement (L)11.04
Working formDirect injection, turbocharged, electronic full speed regulation
Ground specific pressure (Kpa)78.2
Rotation speed (rpm)9.1
Climbing ability (%)70/35 °
Bucket digging force (kN)278
Rod digging force (kN)233
Travel speed (km/h)3.0/4.0/5.5
Rotary hydraulic motor typeAxial plunger type ×1
Type of walking hydraulic motorAxial plunger type x 2
Maximum flow of main pump (l/min)690
Traveling Hydraulic Circuit (Mpa)37.3
Rotary Hydraulic Circuit (Mpa)27.9
Control Hydraulic Circuit (Mpa)3.2 Pilot oil circuit
Hydraulic crushing pipeline is standardno
Bucket cylinders - Number × diameter × stroke (mm)160 * 1270 * 110
Bucket rod cylinders - Number × diameter × stroke (mm)185 * 1985 * 130
Boom cylinders - Number × diameter × stroke (mm)160 * 1570 * 110
Fuel Tank (L)650
Hydraulic Tank (L)248
Engine Oil changes (L)37
Coolant (L)36
Total transport length (mm)11940
Total transport width (mm)3340
Total transport height (mm)3660
Full cab height (mm)3285
Counterweight ground clearance (mm)1320
Minimum ground clearance (mm)567
Back end turning radius (mm)3605
Total track length (mm)5055
Track gauge (mm)2740
Track plate width (mm)600
Total track width (mm)3340
Track ground length (mm)4020
Maximum digging radius (mm)12005
Maximum digging depth (mm)7790
Maximum excavation height (mm)10925
Maximum unloading height (mm)7625
Maximum vertical digging depth (mm)6600
Bulldozer lift or depth (mm)No dodging plate
Maximum excavation radius of stop surface (mm)11800
see more

Overview

No.1085409

Brand Name:

Komatsu

Model Number:

PC400-8

Year:

2020

Location:

Fujian China
