Product Description
With a robust 50-ton working weight and a powerful SAA6D125E-5 engine, this 2021 Komatsu PC500LC-10M0 excavator is designed for demanding site tasks. Featuring a 2.5-3.22 m³ bucket capacity, it excels in digging, grading, and demolition. The machine's 7060 mm boom and 3380 mm rod ensure extensive reach and versatility.
- Rated power: 269 kW at 1900 rpm
- Bucket digging force: 267 kN
- Maximum tractive force: 329 kN
- Travel speed: 3.0-5.5 km/h
- Maximum flow of main pump: 690 l/min
Located in 浙江金华, this excavator is ready to work immediately, providing reliable performance and efficiency. Its water-cooled, 6-cylinder engine ensures consistent operation, while the variable piston pump delivers precise control. Whether you need to dig, grade, or demolish, this Komatsu model is equipped to handle your toughest jobs.
| Specifications | Value |
|---|---|
| No. | 1002021 |
| Tonnage (tons) | 50 |
| Working weight (kg) | 49800 |
| Bucket capacity (m³) | 2.5-3.22 |
| Boom length (mm) | 7060 |
| Rod length (mm) | 3380 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | SAA6D125E-5 |
| Rated power (kw/rpm) | 269/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 125*150 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11.04 |
| Ground specific pressure (Kpa) | 87 |
| Rotation speed (rpm) | 9.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 267 |
| Rod digging force (kN) | 228 |
| Maximum tractive force (kN) | 329 |
| Travel speed (km/h) | 3.0-5.5 |
| Maximum flow of main pump (l/min) | 690 |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Rotary Hydraulic Circuit (Mpa) | 27.9 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 37.3 |
| Pilot Oil Circuit (MPa) | 3.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-160*1350 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-185*1985 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-170*1570 |
| Fuel Tank (L) | 640 |
| Hydraulic Tank (L) | 279 |
| Engine Oil changes (L) | 37 |
| Coolant (L) | 45 |
| Total transport length (mm) | 12260 |
| Total transport width (mm) | 3580 |
| Total transport height (mm) | 3460 |
| Counterweight ground clearance (mm) | 1385 |
| Minimum ground clearance (mm) | 570 |
| Minimum turning radius of front working device (mm) | 5050 |
| Back end turning radius (mm) | 3765 |
| Total track length (mm) | 5385 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4350 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 11985 |
| Maximum digging depth (mm) | 7695 |
| Maximum excavation height (mm) | 10885 |
| Maximum unloading height (mm) | 7650 |
| Maximum vertical digging depth (mm) | 6335 |
| Maximum excavation radius of stop surface (mm) | 11760 |
