Product Description
Strengthen your fleet capacity with this 2019 Sany SY195C excavator, currently located in Guilin, Guangxi. Built for contractors managing multiple job sites, this 19-ton workhorse delivers consistent performance with its 118kW 4M50 engine and proven hydraulic system. Operating weight of 20,900kg provides stability across varied terrain, while the 0.8-1.1m³ bucket capacity handles material efficiently without compromising cycle times.
Key specifications include:
- Maximum digging reach of 10,280mm and depth of 6,600mm for versatile applications
- 138kN bucket digging force and 103kN arm force tackle demanding excavation tasks
- 340L fuel tank and 239L hydraulic reservoir minimize downtime during extended shifts
- Compact transport dimensions (9,680mm length) facilitate quick mobilization between sites
- 70% gradeability and 47.3kPa ground pressure adapt to challenging site conditions
Made in China with traditional power configuration, this unit serves as an ideal backup machine or fleet expansion option for contractors requiring reliable mid-size excavation capacity. Ready to integrate seamlessly into existing operations.
| Specifications | Value |
|---|---|
| No. | 1005573 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
