Product Description
Built for demanding excavation work, this 2016 Sany SY205C delivers reliable performance in a proven 20-ton platform. Operators benefit from enhanced visibility across the 10,280mm maximum digging radius, while the spacious cab design reduces fatigue during extended shifts. Powered by a 118kW engine at 2000rpm, this machine generates 138kN bucket digging force and 109kN arm digging force for efficient material handling.
- Operating weight: 21,500kg with 0.9-1.1m³ bucket capacity
- Superior stability: 47.3kPa ground pressure distributes load evenly across 600mm track plates
- Compact footprint: 2,900mm rear turning radius enables work in confined spaces
- Impressive reach: 6,600mm maximum digging depth and 9,600mm excavation height
- Dual travel speeds (5.4/3.3 km/h) optimize productivity and precision positioning
- 70% grading ability (35°) tackles challenging terrain with confidence
- Currently located in Luzhou, Sichuan, ready for international shipping
Designed with operator comfort in mind, the SY205C features intuitive controls and reduced vibration levels characteristic of Sany's mid-2010s engineering advancements.
| Specifications | Value |
|---|---|
| No. | 1021156 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
