Product Description
Built for demanding jobsites, this 2019 Sany SY205C excavator delivers reliable 20-ton performance with operator-centric engineering. Powered by a 118kW engine at 2000 rpm, it combines robust digging force—138kN bucket and 109kN arm—with exceptional maneuverability for medium to heavy-duty applications.
Operators benefit from superior visibility and stability throughout the working envelope. A spacious cab positioned at 3075mm height provides commanding sightlines across the 10,280mm maximum dig radius and 6,600mm dig depth. Low ground pressure of 47.3kPa ensures stable operation on varied terrain, while the 2,900mm rear turning radius enables confident work in confined spaces.
Key Operator Advantages:
- 440mm ground clearance and 70% gradeability for challenging terrain navigation
- Smooth 11 rpm rotation speed with minimal overhang (2,900mm) reduces repositioning
- Dual travel speeds (5.4/3.3 km/h) optimize productivity and precision control
- 0.9-1.1m³ backhoe bucket capacity handles diverse material loading tasks
- Compact 2,980mm transport width simplifies relocation between sites
Currently located in Jiangsu, China, this machine offers prove
| Specifications | Value |
|---|---|
| No. | 1022937 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
