Product Description
This 2021 Sany SY225C hydraulic excavator represents a reliable solution for medium-duty construction and earthmoving applications. As part of Sany's proven C-series lineup, this 22-ton class machine combines robust build quality with operational efficiency, making it suitable for contractors seeking dependable performance in demanding environments.
Currently located in Zhejiang, China, this unit offers an excellent opportunity for businesses looking to expand their fleet with late-model equipment. The SY225C is engineered for versatility across applications including trenching, material handling, and site development work.
- Manufacturing Year: 2021
- Operating Weight Class: Approximately 22 tonnes
- Machine Type: Crawler Excavator
- Current Location: Zhejiang Province, China
- Manufacturer: Sany Heavy Industry
For detailed specifications, current machine condition assessment, and export documentation assistance, please contact our sales team.
| Specifications | Value |
|---|---|
| No. | 1084300 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22300 |
| Bucket capacity (m³) | 1.1~1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 30.9 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Counterweight ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
