Product Description
Engineered for precision and operator comfort, this 2021 Sany SY245H excavator delivers reliable performance across demanding jobsites. Powered by a robust D06FRC engine producing 147 kW at 2100 rpm with 750 N.m of torque, this 24-ton machine combines hydraulic efficiency with exceptional control. Operators benefit from excellent cabin visibility and ergonomic design, enabling confident maneuvering in confined spaces with a 3,800 mm minimum turning radius and 470 mm ground clearance.
- Working weight: 25,500 kg with 1.3-1.5 m³ bucket capacity
- Maximum digging reach: 10,225 mm with 6,705 mm depth capability
- Bucket digging force: 175 kN; stick force: 120 kN
- Water-cooled 6-cylinder engine (6.373 L displacement)
- 70% grading ability with 53.2 kPa ground pressure
- 475 L fuel capacity for extended operation
- Located in Putian, Fujian—ready for international shipping
Built in China with proven Sany engineering, this SY245H offers stability and responsive handling for operators prioritizing productivity and comfort in medium to heavy-duty excavation work.
| Specifications | Value |
|---|---|
| No. | 1021657 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
