2024 Sany SY305H

1/9
Buy Sany SY305H Used Excavator / 1
Buy Sany SY305H Used Excavator / 2
Buy Sany SY305H Used Excavator / 3
Buy Sany SY305H Used Excavator / 4
Buy Sany SY305H Used Excavator / 5
Buy Sany SY305H Used Excavator / 6
Buy Sany SY305H Used Excavator / 7
Buy Sany SY305H Used Excavator / 8
Buy Sany SY305H Used Excavator / 9

Product Description

This 2024 Sany SY305H excavator represents an exceptional opportunity for earthmoving contractors seeking reliable, low-hour equipment. Manufactured by one of China's leading heavy equipment producers, this 30-ton class hydraulic excavator comes from a single owner with verified actual meter reading of approximately 3,000 hours—minimal use for a machine of this caliber.

The unit has been maintained in excellent working condition and is available for immediate deployment on earthwork projects. Located in Zhejiang, China, this machine offers professional operators proven performance in excavation, trenching, and site development applications.

  • Year: 2024
  • Model: Sany SY305H
  • Operating Hours: ~3,000
  • Ownership: Single owner
  • Condition: Ready for work
  • Major Components: 3-month warranty included
  • Location: Zhejiang, China
SpecificationsValue
No.1171275
Tonnage (tons)30
Working weight (kg)31500
Bucket capacity (m³)1.65~2.0(1.65)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeIsuzu GH-6HK1
Rated power (kw/rpm)212/2000
Cooling modewater-cooling
Maximum torque (N.m)1080/1500
Number of cylinders (PCS)6
Displacement (L)7.79
Ground specific pressure (Kpa)62.3
Rotation speed (rpm)9.0
Climbing ability (%)70% (35°)
Bucket digging force (kN)204
Rod digging force (kN)153
Travel speed (km/h)5.4/3.2
Fuel Tank (L)540
Hydraulic Tank (L)380
Engine Oil changes (L)2*4.0
Coolant (L)35
Total transport length (mm)10667
Total transport width (mm)3190
Total transport height (mm)3470
Full cab height (mm)3280
Minimum ground clearance (mm)550
Minimum turning radius of front working device (mm)4000
Back end turning radius (mm)3315
Onboard width (mm)3175
Total track length (mm)4840
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3916
Maximum height at minimum turning radius (mm)8405
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)8
Number of track plates (single side) (PCS)47
Maximum digging radius (mm)10870
Maximum digging depth (mm)6815
Maximum excavation height (mm)10497
Maximum unloading height (mm)7359
Maximum vertical digging depth (mm)6170
see more

Overview

No.1171275

Brand Name:

Sany

Model Number:

SY305H

Year:

2024

Location:

Zhejiang China

Pub Date:

Are you interested in this machine?

Please contact us
