2022 Sumitomo SH210-5

1/9
Buy Sumitomo SH210-5 Used Excavator / 1
Buy Sumitomo SH210-5 Used Excavator / 2
Buy Sumitomo SH210-5 Used Excavator / 3
Buy Sumitomo SH210-5 Used Excavator / 4
Buy Sumitomo SH210-5 Used Excavator / 5
Buy Sumitomo SH210-5 Used Excavator / 6
Buy Sumitomo SH210-5 Used Excavator / 7
Buy Sumitomo SH210-5 Used Excavator / 8
Buy Sumitomo SH210-5 Used Excavator / 9

Product Description

Well-maintained 2022 Sumitomo SH210-5 hydraulic excavator available in Jiangsu, China. This 21-ton class machine features proven reliability and excellent operational performance, ready for immediate deployment on your worksite.

Key highlights:

  • Recent model year with low operating hours
  • Verified performance condition - inspection-ready
  • Sumitomo's renowned hydraulic system for efficient digging and lifting
  • Competitively priced for quick acquisition
  • Suitable for construction, excavation, and earthmoving applications

The SH210-5 delivers dependable performance with balanced power and fuel efficiency. Machine is located on-site in Jiangsu province for buyer inspection. Contact us for detailed specifications, current photos, and competitive pricing on this quality used excavator.

SpecificationsValue
No.1138732
Tonnage (tons)21
Working weight (kg)20600
Bucket capacity (m³)0.9-1.0
Boom length (mm)5700
Rod length (mm)2900
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine type
Rated power (kw/rpm)117.3/1800
Cylinder diameter × stroke (mm)115 x 125
Number of cylinders (PCS)4
Displacement (L)5.193
Ground specific pressure (Kpa)45
Rotation speed (rpm)11.5
Climbing ability (%)70
Bucket digging force (kN)142
Rod digging force (kN)103
Travel speed (km/h)3.4/5.6
Type of walking hydraulic motorVariable axial piston motor
Maximum flow of main pump (l/min)422
Main pump type
Bucket cylinders - Number × diameter × stroke (mm)
Bucket rod cylinders - Number × diameter × stroke (mm)140 x 1460
Boom cylinders - Number × diameter × stroke (mm)
Fuel Tank (L)410
Hydraulic Tank (L)147
Engine Oil changes (L)23.1
Coolant (L)26
Hydraulic System (L)240
Total transport length (mm)9400
Total transport width (mm)2800
Total transport height (mm)2970
Counterweight ground clearance (mm)1040
Minimum ground clearance (mm)460
Minimum turning radius of front working device (mm)3600
Back end turning radius (mm)2720
Total track length (mm)4180
Track gauge (mm)2200
Track plate width (mm)600
Total track width (mm)2800
Track ground length (mm)3370
Maximum digging radius (mm)9900
Maximum digging depth (mm)6650
Maximum excavation height (mm)9610
Maximum unloading height (mm)6810
Maximum vertical digging depth (mm)5960
see more

Overview

No.1138732

Brand Name:

Sumitomo

Model Number:

SH210-5

Year:

2022

Location:

Jiangsu China

Pub Date
