Product Description
Engineered with precision, this 2016 Sumitomo SH350-5 excavator delivers exceptional performance through its robust AH-6HK1XYSS engine, generating 202 kW at 2000 rpm with a 7.79L displacement. The advanced hydraulic system operates at main overflow pressures of 34.3/37.3 MPa, providing superior digging force capabilities: 229 kN bucket force and 164 kN arm force. Currently located in Hebei, this 35-ton class machine represents joint venture manufacturing excellence.
Key technical specifications include:
- Operating weight: 35,200 kg with bucket capacity range of 1.2-1.8 m³
- Maximum digging reach: 11,170 mm with 7,340 mm depth capability
- Maximum digging height: 10,370 mm and unloading height of 7,230 mm
- Travel speeds: 5.5/3.5 km/h with 264 kN maximum tractive force
- Fuel capacity: 580L tank supporting extended operation cycles
- Ground pressure: 71 kPa ensuring minimal surface impact
- Rotation speed: 9.8 rpm for efficient positioning
Built for demanding applications, this model combines proven reliability with comprehensive working dimensions suited for heavy construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 1010049 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | AH-6HK1XYSS |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
