Product Description
This 2021 Sumitomo SH380-5 hydraulic excavator offers reliable performance for demanding earthmoving applications. Located in Zhejiang, China, this machine represents Sumitomo's proven engineering with low operating hours for its model year. The SH380-5 is built for productivity in quarrying, large-scale excavation, and heavy construction projects.
Key features include:
- Operating weight approximately 38 tons for stable digging performance
- Fuel-efficient engine meeting emission standards
- Durable undercarriage designed for extended service life
- Spacious operator cabin with ergonomic controls
- Hydraulic system engineered for smooth, responsive operation
Available for inspection in Zhejiang province. Suitable for contractors and fleet operators seeking dependable used equipment with significant service life remaining. Contact us for detailed specifications, current condition report, and export documentation assistance.
| Specifications | Value |
|---|---|
| No. | 1169071 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 36600 |
| Bucket capacity (m³) | 1.8 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AH-6HK1X |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.790 |
| Ground specific pressure (Kpa) | 68 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | Variable capacity piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 175 |
| Hydraulic System (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4980 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
