2020 Volvo EC140B

1/9
Buy Volvo EC140B Used Excavator / 1
Buy Volvo EC140B Used Excavator / 2
Buy Volvo EC140B Used Excavator / 3
Buy Volvo EC140B Used Excavator / 4
Buy Volvo EC140B Used Excavator / 5
Buy Volvo EC140B Used Excavator / 6
Buy Volvo EC140B Used Excavator / 7
Buy Volvo EC140B Used Excavator / 8
Buy Volvo EC140B Used Excavator / 9

Product Description

This 2020 Volvo EC140B excavator represents excellent value in the mid-size excavator segment. Currently located in Guangdong, China, this machine features robust hydraulic performance and reinforced undercarriage components designed for demanding job site conditions. The EC140B is known for its reliable fuel efficiency and operator comfort in its class.

Key highlights include:

  • Well-maintained hydraulic system delivering consistent performance
  • Heavy-duty track assembly engineered for extended service life
  • Low operating hours (approximately 80,000+ RMB value range)
  • Volvo's proven powertrain and component reliability
  • Suitable for earthmoving, excavation, and general construction applications

This unit is available for immediate inspection in Guangdong. Contact our sales team for detailed specifications, current condition reports, and shipping arrangements to your location.

SpecificationsValue
No.1120687
Tonnage (tons)14
Working weight (kg)13800
Bucket capacity (m³)0.55-0.93
Boom length (mm)4600
Rod length (mm)2500
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeVolvo D4D
Rated power (kw/rpm)73/2100
Cylinder diameter × stroke (mm)101 x 126
Number of cylinders (PCS)4
Displacement (L)4
Ground specific pressure (Kpa)34.6
Rotation speed (rpm)11
Climbing ability (%)70%
Bucket digging force (kN)93.2/98.1
Rod digging force (kN)63.7/67.7
Travel speed (km/h)5.5/3.2
Maximum flow of main pump (l/min)118*2+21
Main pump typeVariable axial piston pump ×2+ gear pump
Bucket cylinders - Number × diameter × stroke (mm)100 x 865
Bucket rod cylinders - Number × diameter × stroke (mm)120 x 1045
Boom cylinders - Number × diameter × stroke (mm)105 x 980
Fuel Tank (L)260
Hydraulic Tank (L)100
Engine Oil changes (L)15.5
Coolant (L)20.3
Total transport length (mm)7700
Total transport width (mm)2590
Total transport height (mm)2830
Full cab height (mm)2830
Counterweight ground clearance (mm)900
Minimum ground clearance (mm)430
Back end turning radius (mm)2200
Track gauge (mm)1990
Total track width (mm)2590
Track ground length (mm)3000
see more

Overview

No.1120687

Brand Name:

Volvo

Model Number:

EC140B

Year:

2020

Location:

Guangdong China
