Product Description
Discover the reliability and performance of the 2017 Volvo EC170D, available for purchase in Guangdong, China. This robust excavator has accumulated just over 10,000 operational hours, making it a solid choice for your construction or excavation projects. Known for its efficiency and durability, the EC170D is equipped with advanced technology to enhance productivity and reduce operating costs. Ideal for a variety of applications, this machine offers excellent digging force, stability, and maneuverability. Whether you're tackling tough terrain or precise operations, the EC170D delivers the power and precision needed to get the job done right. Consider this well-maintained unit for a cost-effective solution that doesn't compromise on quality.
- Year: 2017
- Brand: Volvo
- Model: EC170D
- Location: Guangdong, China
- Operational Hours: Over 10,000
| Specifications | Value |
|---|---|
| No. | 1135225 |
| Tonnage (tons) | 17 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D4E |
| Rated power (kw/rpm) | 90-91/2200 |
| Cylinder diameter × stroke (mm) | 101 x 126 |
| Maximum torque (N.m) | 495/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.038 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 101.3-116.7 |
| Rod digging force (kN) | 71.9-98.2 |
| Maximum tractive force (kN) | 145 |
| Travel speed (km/h) | 3.1/5.6 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Main pump type | Two variable displacement axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 34.3 / 36.3 |
| Pilot pump flow (L/min) | 2 x 150 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1×105 x 1 000 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1×105 x 1 345 |
| Boom cylinders - Number × diameter × stroke (mm) | 2×115 x 1 165 |
| Fuel Tank (L) | 253 |
| Hydraulic Tank (L) | 111 |
| Engine Oil changes (L) | 16.5 |
| Coolant (L) | 23.7 |
| Hydraulic System (L) | 225 |
| Total transport length (mm) | 8800 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2900 |
| Counterweight ground clearance (mm) | 1010 |
| Minimum ground clearance (mm) | 460 |
| Onboard width (mm) | 2490 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 500 / 600 / 700 / 800 / 900 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 8633-9344 |
| Maximum digging depth (mm) | 5740-6440 |
| Maximum unloading height (mm) | 6170-6539 |
| Maximum vertical digging depth (mm) | 3698-4133 |
| Maximum excavation radius of stop surface (mm) | 8491-9188 |
