2020 Volvo EC350DL

1/9
Buy Volvo EC350DL Used Excavator / 1
Buy Volvo EC350DL Used Excavator / 2
Buy Volvo EC350DL Used Excavator / 3
Buy Volvo EC350DL Used Excavator / 4
Buy Volvo EC350DL Used Excavator / 5
Buy Volvo EC350DL Used Excavator / 6
Buy Volvo EC350DL Used Excavator / 7
Buy Volvo EC350DL Used Excavator / 8
Buy Volvo EC350DL Used Excavator / 9

Product Description

Discover the exceptional 2020 Volvo EC350DL, a robust and reliable excavator available for purchase in Peking, China. This machine is in its original condition, offering proven performance that meets the rigorous demands of construction and excavation projects. The EC350DL is designed to deliver high productivity, efficiency, and durability, making it an ideal choice for heavy-duty applications. With its solid reputation for quality and reliability, this excavator is ready to take on your next project with ease.

  • Year: 2020
  • Brand: Volvo
  • Model: EC350DL
  • Location: Peking, China
  • Condition: Original, excellent working condition
SpecificationsValue
No.1075597
Tonnage (tons)35
Working weight (kg)34,300 - 38,700
Bucket capacity (m³)1 - 2.53
Boom length (mm)6450
Rod length (mm)2600
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD8K
Rated power (kw/rpm)210/1800
Cooling modewater-cooling
Cylinder diameter × stroke (mm)110 x 138
Maximum torque (N.m)1340 / 1350
Number of cylinders (PCS)6
Displacement (L)7.8
Rotation speed (rpm)10.3
Climbing ability (%)35
Bucket digging force (kN)177
Rod digging force (kN)187
Maximum tractive force (kN)261
Travel speed (km/h)3.3 / 5.1
Turning torque (Nm)126
Maximum flow of main pump (l/min)2 x 288
Traveling Hydraulic Circuit (Mpa)33.3
Rotary Hydraulic Circuit (Mpa)27.9
Working Hydraulic Circuit (Mpa)33.3 / 36.3
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)580
Hydraulic Tank (L)215
Engine Oil changes (L)32
Coolant (L)41
Hydraulic System (L)465
Total transport length (mm)11270
Total transport width (mm)3190
Full cab height (mm)3230
Counterweight ground clearance (mm)1180
Minimum ground clearance (mm)500
Onboard width (mm)2990
Total track length (mm)4950
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)4020
Maximum digging radius (mm)10590
Maximum digging depth (mm)6880
Maximum excavation height (mm)10170
Maximum unloading height (mm)7060
Maximum vertical digging depth (mm)5440
Maximum excavation radius of stop surface (mm)10370
