Product Description
Proven performance meets Volvo engineering in this robust 8-ton excavator from 2016. With over seven years of operational history, the EC80D demonstrates the exceptional build quality that makes it a reliable workhorse on demanding job sites across Fujian and beyond. Powered by the dependable Volvo D3.4A engine delivering 42kW at 2100 rpm, this machine combines fuel efficiency with consistent power delivery for extended productivity.
Built to last through challenging conditions, this compact excavator offers impressive capabilities within its class:
- Maximum digging depth of 4,100mm with 6,420mm reach radius
- Bucket digging force of 49kN and rod force of 39kN for tough material handling
- Compact transport dimensions (6,165mm length) for easy site mobility
- 0.34m³ bucket capacity optimized for versatility
- Joint venture manufacturing ensures quality components and parts availability
Operating weight of 7,450kg provides stability without sacrificing maneuverability. Dual travel speeds (2.6/5.1 km/h) enhance operational flexibility. This Korea-origin excavator represents proven durability with substantial service life remaining for contractors seeking dependable perfor
| Specifications | Value |
|---|---|
| No. | 1021665 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.34 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D3.4A |
| Rated power (kw/rpm) | 42/2100 |
| Maximum torque (N.m) | 243 |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 39 |
| Maximum tractive force (kN) | 65 |
| Travel speed (km/h) | 2.6/5.1 |
| Total transport length (mm) | 6165 |
| Total transport width (mm) | 2300 |
| Total transport height (mm) | 2655 |
| Full cab height (mm) | 2655 |
| Counterweight ground clearance (mm) | 755 |
| Minimum ground clearance (mm) | 400 |
| Minimum turning radius of front working device (mm) | 1690 |
| Back end turning radius (mm) | 1750 |
| Onboard width (mm) | 2280 |
| Total track length (mm) | 2850 |
| Track gauge (mm) | 1850 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2300 |
| Track ground length (mm) | 2200 |
| Maximum digging radius (mm) | 6420 |
| Maximum digging depth (mm) | 4100 |
| Maximum excavation height (mm) | 7130 |
| Maximum unloading height (mm) | 5150 |
| Maximum vertical digging depth (mm) | 3530 |
| Maximum excavation radius of stop surface (mm) | 6270 |
| Maximum effective digging depth (mm) | 3740 |
