Product Description
Proven performance meets industrial-grade durability in this 2019 XCMG LW60G wheel loader, currently located in Luzhou, Sichuan. Built with a robust 178kW engine and 8.29L displacement, this 6-ton capacity machine delivers 198kN of digging force with a 3.3m³ bucket—engineered for demanding material handling and loading operations across construction, mining, and aggregate applications.
XCMG's reputation as China's leading construction equipment manufacturer ensures exceptional parts availability and strong resale value in the used market. With an operating weight of 20,500kg and maximum tractive force of 165kN, this loader tackles 28-degree grades while maintaining stability. Four-speed transmission offers versatility from 6km/h precision work to 35km/h transport speeds. The 3,400mm wheelbase and 6,482mm turning radius provide maneuverability in confined job sites.
- Rated Load: 6,000kg | Bucket Capacity: 3.3m³
- Engine Power: 178kW @ 2,200rpm
- Unloading Height: 3,100mm | Reach: 1,250mm (45° angle)
- Fuel Tank: 250L | Hydraulic Tank: 180L
- Dimensions: 8,593mm (L) × 2,833mm (W) × 3,534mm (H)
| Specifications | Value |
|---|---|
| No. | 1021797 |
| Engine type | |
| Rated power (kw/rpm) | 178/2200 |
| Working form | |
| Exhaust volume (L) | 8.29 |
| Bucket capacity (m³) | 3.3 |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Digging force (lifting force) (kN) | 198 |
| Machine operating weight (kg) | 20500 |
| Unloading height - Unloading Angle 45°(mm) | 3100 |
| Unloading distance - Unloading Angle 45°(mm) | 1250 |
| Maximum tractive force (kN) | 165 |
| Maximum climbing ability (°) | 28 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 180 |
| Engine Oil (L) | 27.6 |
| Wheelbase (mm) | 3400 |
| Wheel base (mm) | 2200 |
| Minimum ground clearance (mm) | 450 |
| Machine length (mm) | 8593 |
| Machine width (mm) | 2833 |
| Machine height (mm) | 3534 |
| Minimum turning radius of outer wheel center line | 6482 |
| Turning radius - Outside of bucket (mm) | 7525 |
| Rated working pressure (bars) | 16 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 6 |
| Speed 2 (km/h) | 11 |
| Speed 3 (km/h) | 22 |
| Speed 4 (km/h) | 35 |
