Product Description
Strengthen your fleet with this 2021 XCMG LW60G wheel loader, currently located in Jiangsu and ready for immediate deployment. Rated at 6,000 kg capacity with a generous 3.3 m³ bucket, this machine delivers consistent performance across material handling, loading, and stockpile management operations. Powered by a 178 kW engine at 2,200 rpm, the LW60G generates 198 kN of digging force while maintaining a 20,500 kg operating weight for optimal stability.
Built for contractors managing multiple job sites, this loader offers:
- Four-speed transmission reaching 35 km/h for rapid repositioning between work zones
- 3,100 mm unloading height with 1,250 mm reach at 45° dump angle
- 165 kN maximum tractive force and 28° climbing capability for challenging terrain
- 6.5-second lift cycle and 12-second combined cycle time maximizing productivity
- 250 L fuel capacity supporting extended operational shifts
With compact dimensions (8,593 mm length, 2,833 mm width) and a 6,482 mm turning radius, this XCMG integrates seamlessly into existing fleets requiring dependable backup capacity or project expansion capabilities.
| Specifications | Value |
|---|---|
| No. | 1021350 |
| Engine type | |
| Rated power (kw/rpm) | 178/2200 |
| Working form | |
| Exhaust volume (L) | 8.29 |
| Bucket capacity (m³) | 3.3 |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Digging force (lifting force) (kN) | 198 |
| Machine operating weight (kg) | 20500 |
| Unloading height - Unloading Angle 45°(mm) | 3100 |
| Unloading distance - Unloading Angle 45°(mm) | 1250 |
| Maximum tractive force (kN) | 165 |
| Maximum climbing ability (°) | 28 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 180 |
| Engine Oil (L) | 27.6 |
| Wheelbase (mm) | 3400 |
| Wheel base (mm) | 2200 |
| Minimum ground clearance (mm) | 450 |
| Machine length (mm) | 8593 |
| Machine width (mm) | 2833 |
| Machine height (mm) | 3534 |
| Minimum turning radius of outer wheel center line | 6482 |
| Turning radius - Outside of bucket (mm) | 7525 |
| Rated working pressure (bars) | 16 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 6 |
| Speed 2 (km/h) | 11 |
| Speed 3 (km/h) | 22 |
| Speed 4 (km/h) | 35 |
