Product Description
Strengthen your fleet with this 2021 XCMG LW60G wheel loader, currently positioned in Guizhou and ready for immediate deployment. Powered by a robust 178 kW engine paired with an 8.29L displacement system, this 6-ton loader delivers consistent performance across demanding jobsites. The 3.3 m³ bucket capacity and 198 kN digging force handle material movement efficiently, while the 20,500 kg operating weight provides stability during heavy-cycle operations.
Built for contractors managing multiple projects simultaneously, this unit offers:
- 3,100 mm unloading height for standard truck loading applications
- 165 kN maximum tractive force with 28° climbing capability for varied terrain
- Four-speed transmission (6-35 km/h) optimizing travel between work zones
- 250L fuel tank supporting extended shifts without frequent refueling
- 7,525 mm turning radius managing confined site navigation
Ideal as a backup machine during peak season or as a dedicated unit for secondary sites. The 3,400 mm wheelbase and 450 mm ground clearance maintain operational versatility across construction, aggregate, and material handling applications. Factory hydraulics operate at 16 bars rated pressure
| Specifications | Value |
|---|---|
| No. | 1021749 |
| Engine type | |
| Rated power (kw/rpm) | 178/2200 |
| Working form | |
| Exhaust volume (L) | 8.29 |
| Bucket capacity (m³) | 3.3 |
| Rated load (tons) | |
| Rated load (kg) | 6000 |
| Digging force (lifting force) (kN) | 198 |
| Machine operating weight (kg) | 20500 |
| Unloading height - Unloading Angle 45°(mm) | 3100 |
| Unloading distance - Unloading Angle 45°(mm) | 1250 |
| Maximum tractive force (kN) | 165 |
| Maximum climbing ability (°) | 28 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 180 |
| Engine Oil (L) | 27.6 |
| Wheelbase (mm) | 3400 |
| Wheel base (mm) | 2200 |
| Minimum ground clearance (mm) | 450 |
| Machine length (mm) | 8593 |
| Machine width (mm) | 2833 |
| Machine height (mm) | 3534 |
| Minimum turning radius of outer wheel center line | 6482 |
| Turning radius - Outside of bucket (mm) | 7525 |
| Rated working pressure (bars) | 16 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.5 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 6 |
| Speed 2 (km/h) | 11 |
| Speed 3 (km/h) | 22 |
| Speed 4 (km/h) | 35 |
