Product Description
Engineered for precision work in confined spaces, this 2017 XCMG XE18 mini excavator delivers reliable performance with operator-centric design. Powered by a Yanmar 3TNV82A engine producing 16.5kW at 2200 rpm, this 1.78-ton machine combines compact dimensions (3760mm total length, 1300mm width) with impressive maneuverability. The 1675mm minimum turning radius and 1190mm rear swing radius enable efficient operation in tight urban environments and restricted job sites.
Operator comfort and control define this model's capabilities. Dual Japanese variable pumps paired with plunger hydraulic motors provide responsive handling across all functions. Visibility remains unobstructed thanks to the compact counterweight design and 509mm ground clearance. The machine achieves 3915mm maximum digging reach and 2285mm digging depth, while bucket digging force of 13.9kN ensures productive excavation cycles.
- Stable 25.3kPa ground pressure minimizes surface disturbance
- Dual-speed travel system: 4.4/2.4 km/h for versatile positioning
- 30° climbing ability handles challenging terrain
- Water-cooled 3-cylinder engine ensures consistent performance
- Standard hydraulic crushing pipeline expands attach
| Specifications | Value |
|---|---|
| No. | 994581 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
