Product Description
Expand your fleet capacity with this 2016 XCMG XE235C excavator, currently positioned in Hunan and ready for immediate deployment. Built around a proven 6-cylinder CC-6BG1TRP engine delivering 637 N·m of torque, this 23-ton workhorse brings reliable performance to high-volume construction and earthmoving operations. Operating weight of 23,500 kg combines with 0.9–1.1 m³ bucket capacity to handle medium-duty excavation, trenching, and material handling across diverse jobsites.
Contractors managing multiple projects will appreciate the practical specifications:
- Maximum digging reach of 10,240 mm and depth capability to 6,960 mm
- Dual main pumps flowing 2 × 246 L/min for responsive hydraulic performance
- Bucket digging force of 176 kN and stick force of 125 kN
- 400-liter fuel tank and 240-liter hydraulic reservoir minimize refueling downtime
- Water-cooled engine system ensures consistent performance in demanding conditions
Whether you need backup capacity during peak season or a dedicated unit for a long-term contract, this XE235C integrates seamlessly into existing XCMG fleets while offering standalone reliability for independent operators.
| Specifications | Value |
|---|---|
| No. | 1019295 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 23500 |
| Bucket capacity (m³) | 0.9 ~ 1.1 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2960 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | CC-6BG1TRP |
| Cooling mode | water-cooling |
| Maximum torque (N.m/rpm) | 637/1800 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.494 |
| Ground specific pressure (Kpa) | 48.9 |
| Rotation speed (rpm) | 12.1 |
| Climbing ability (%) | 35 or less |
| Bucket digging force (kN) | 176 |
| Rod digging force (kN) | 125 |
| Maximum tractive force (kN) | 194.8 |
| Travel speed (km/h) | 6.0/4.0 |
| Maximum flow of main pump (l/min) | 2 x 246 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 10160 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 485 |
| Back end turning radius (mm) | 2985 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6960 |
| Maximum excavation height (mm) | 9595 |
| Maximum unloading height (mm) | 6725 |
| Maximum vertical digging depth (mm) | 6090 |
