Product Description
Expand your operational capacity with this 2016 XCMG XE265C hydraulic excavator, currently available in Zhejiang Shaoxing. Built for contractors demanding reliable fleet integration, this 26-ton workhorse delivers consistent performance across demolition, earthmoving, and heavy excavation projects. Powered by an ISUZU CC-6BG1TRP-05 engine generating 135.5 kW at 2150 rpm, this machine combines proven mechanical durability with responsive hydraulic systems.
- Operating weight: 25,500 kg with 1.05–1.25 m³ bucket capacity
- Maximum digging reach: 10,240 mm; maximum digging depth: 6,895 mm
- Dual plunger pumps provide 2 × 256 L/min flow for multi-function efficiency
- Bucket digging force: 161 kN; arm digging force: 125 kN
- Compact transport dimensions (10,160 × 3,190 × 3,100 mm) facilitate jobsite mobility
- 400 L fuel tank and 240 L hydraulic reservoir minimize downtime
Ideal as a backup unit or fleet expansion asset, this China-manufactured excavator offers dependable performance metrics suited for medium to heavy-duty applications. Contact Fair Trade Machinery today for detailed specifications and availability.
| Specifications | Value |
|---|---|
| No. | 1019623 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.05 ~ 1.25 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2960 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU CC-6BG1TRP-05 |
| Rated power (kw/rpm) | 135.5/2150 |
| Maximum torque (N.m/rpm) | 637 |
| Ground specific pressure (Kpa) | 50.1 |
| Rotation speed (rpm) | 11.3 |
| Climbing ability (%) | 35 or less |
| Bucket digging force (kN) | 161 |
| Rod digging force (kN) | 125 |
| Maximum tractive force (kN) | 194 |
| Travel speed (km/h) | 5.9/4.0 |
| Main overflow set pressure (Mpa) | 34.3/37 |
| Maximum flow of main pump (l/min) | 2 x 256 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Main pump type | 2 plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 240 |
| Engine Oil changes (L) | 25 |
| Total transport length (mm) | 10160 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3100 |
| Minimum turning radius of front working device (mm) | 3850 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6895 |
| Maximum excavation height (mm) | 9662 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5480 |
| Maximum excavation radius of stop surface (mm) | 6750 |
