Product Description
Built for immediate deployment on demanding jobsites, this 4-ton compact excavator delivers reliable performance across digging, grading, and material handling operations. The XCMG XE40 combines a powerful Yanmar 4TNV88 engine (27.1 kW) with a Japanese Fujikoshi variable pump system, providing consistent hydraulic flow for precise control in confined spaces. With a maximum digging depth of 3,600mm and digging radius of 5,810mm, this machine tackles trenching, foundation work, and utility installation with authority.
Engineered for versatility, the XE40 features a 0.14m³ backhoe bucket generating 23.2kN of digging force, while the 19.3kN rod force powers through compacted soil and clay. The compact 1,650mm transport width enables access to restricted sites, and the 30° climbing ability handles challenging terrain. Water-cooled reliability and a 70-liter hydraulic system ensure sustained operation throughout extended shifts.
- Maximum digging depth: 3,600mm | Maximum reach: 5,810mm
- Yanmar 4-cylinder engine with 27.1kW rated power
- Compact dimensions: 5,455mm length × 1,650mm width
- Plunger hydraulic motors for travel and rotation
- Available in Anhui, ready for immediate site deploym
| Specifications | Value |
|---|---|
| No. | 998851 |
| Tonnage (tons) | 4 |
| Working weight (kg) | 4050 |
| Bucket capacity (m³) | 0.14 |
| Boom length (mm) | 2795 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 4TNV88 |
| Rated power (kw/rpm) | 27.1/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.19 |
| Ground specific pressure (Kpa) | 23.6 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 23.2 |
| Rod digging force (kN) | 19.3 |
| Travel speed (km/h) | 4.2/2.6 |
| Main overflow set pressure (Mpa) | 21 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*110+11 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 21 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Japan Fujikoshi variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 65 |
| Engine Oil changes (L) | 7.4 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5455 |
| Total transport width (mm) | 1650 |
| Total transport height (mm) | 2440 |
| Counterweight ground clearance (mm) | 578 |
| Minimum ground clearance (mm) | 350 |
| Minimum turning radius of front working device (mm) | 2385 |
| Back end turning radius (mm) | 1490 |
| Track gauge (mm) | 1335 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1721 |
| Maximum digging radius (mm) | 5810 |
| Maximum digging depth (mm) | 3600 |
| Maximum excavation height (mm) | 5320 |
| Maximum unloading height (mm) | 3700 |
| Maximum vertical digging depth (mm) | 2250 |
| Bulldozer lift or depth (mm) | 267/365 |
| Dodging plate width × height (mm) | 1650 x 300 |
