Name: Used Excavators 2017 XCMG XE500C
Brand: XCMG
SKU: USED-1040140
Availability: InStock
Rating: 4.4 (01 reviews)

Sany

Caterpillar

XCMG

Hitachi

Komatsu

Doosan

Kobelco

Hyundai

Volvo

Sumitomo

Kato

Case

Yanmar

JohnDeere

Liebherr

Commanding a 50-ton operating weight, this 2017 XCMG XE500C delivers robust performance for large-scale excavation projects. Powered by a Cummins QSM11 engine producing 250 kW at 2100 rpm, operators benefit from consistent power delivery across demanding applications. The spacious cabin provides excellent sightlines to the 2.1–2.5 m³ bucket, enhancing precision during complex digging sequences.

Hydraulic stability comes from dual 360 l/min main pumps and a low ground specific pressure of 85.9 kPa, ensuring balanced weight distribution across varied terrain. With a maximum digging depth of 7,337 mm and digging radius extending to 11,631 mm, this machine handles deep foundation work and wide trenching operations efficiently. The 7,060 mm boom and 2,900 mm arm configuration optimize reach while maintaining structural rigidity.

Control responsiveness is supported by a 3.9 MPa pilot oil circuit, allowing smooth multi-function operation during extended shifts. Currently located in Baoding, Hebei, this XE500C represents proven Chinese engineering for contractors requiring dependable performance in high-volume earthmoving environments.

Built for precision and productivity, this 2021 XCMG LW200 wheel loader combines robust power with operator-centered design. Equipped with a 60kW engine running at 2400 rpm, it delivers a rated load capacity of 2000 kg and a 1.2 m³ bucket, making it highly effective for material handling in construction sites, warehouses, and aggregate yards. Operating weight stands at 7500 kg, providing excellent stability during loading cycles.

Operators benefit from outstanding visibility and responsive controls in the spacious cabin. Quick cycle times—6 seconds for lift and 11 seconds for total cycle—maximize efficiency throughout the workday. Precise articulation steering and a compact 2400 mm wheelbase ensure maneuverability in confined spaces while maintaining solid ground contact. Unloading height reaches 2650 mm at 45°, with a discharge distance of 910 mm for accurate placement.

Key Specifications:
<ul>
<li>Rated Power: 60 kW @ 2400 rpm</li>
<li>Bucket Capacity: 1.2 m³</li>
<li>Operating Weight: 7500 kg</li>
<li>Digging Force: 60 kN</li>
<li>Location: Hangzhou, Zhejiang, China</li>
</ul>

XCMG LW200

Available now in Hangzhou, Zhejiang, this 2016 XCMG XE135D crawler excavator eliminates factory wait times and accelerates your project timeline. Operating at 13 tons with a robust QSF3.8 engine delivering 86kW at 2200 rpm, this machine provides immediate productivity without procurement delays. Water-cooled turbocharged performance meets the demands of infrastructure, earthmoving, and construction applications across Asia and beyond.

<ul>
 <li>Working weight: 13,200 kg with 0.52 m³ bucket capacity</li>
 <li>Maximum digging reach: 8,304 mm / digging depth: 5,546 mm</li>
 <li>Dual main pumps: 125.4 L/min each for responsive hydraulic flow</li>
 <li>Bucket digging force: 99.1 kN / stick force: 68 kN</li>
 <li>Transport dimensions: 7,795 × 2,525 × 2,880 mm</li>
 <li>260L fuel capacity for extended operating shifts</li>
</ul>

Skip months of lead time. Fast deployment from Hangzhou to your site means work begins immediately. Direct injection EFI technology and proven Chinese manufacturing deliver dependable performance at competitive value. Inspect in Zhejiang and mobilize within days.

XCMG XE135D

Rated at 70 tons with a powerful CUMMINS QSX15 engine delivering 336 kW at 1800 rpm, this 2016 XCMG XE700C hydraulic excavator is built for high-volume earthmoving and deep foundation work. A maximum digging depth of 6,900 mm and bucket capacity of 3.1-3.5 m³ enable efficient trenching and mass excavation across construction sites, quarries, and infrastructure projects. Dual plunger pumps provide 2×450 L/min flow for responsive hydraulic performance, while 370 kN bucket digging force cuts through compacted soil and rock with authority.

Currently located in Hangzhou, Zhejiang, this machine arrives site-ready with proven XCMG engineering from Xuzhou. Water-cooled turbocharged operation ensures consistent power delivery during extended shifts. With an 11,580 mm maximum reach and 7,370 mm dump height, material handling stays productive whether loading trucks or placing fill. Track gauge adjustability (2,800/3,350 mm) and 30° climbing ability maintain stability on challenging terrain. Standard backhoe configuration handles grading, demolition, and utility installation without modification. Equipped with 980 L fuel capacity for sustained operation between refills.

XCMG XE700C

Built for mid-sized excavation work, this 2016 Caterpillar 313D delivers 13 tons of proven digging performance. Powered by a Cat C4.2 ACERT engine producing 67 kW, this machine handles daily site demands from foundation trenching to utility installation with consistent hydraulic power and operator precision.

<ul>
 <li>Digging Capacity: 5,580 mm maximum depth with 8,220 mm reach at ground level—ideal for deep trench work and grading operations</li>
 <li>Hydraulic Performance: 82 kN bucket digging force and 127 L/min main pump flow for efficient material loading and cycle times</li>
 <li>Reliable Power: Water-cooled 4.25L engine meets EPA Tier 3 and EU Stage IIIA emission standards</li>
 <li>Work-Ready Specs: 0.52 m³ bucket capacity, 4,650 mm boom, 2,500 mm stick configuration for versatile excavation tasks</li>
 <li>Maneuverability: 2,140 mm rear swing radius and 2,490 mm transport width fit confined jobsites</li>
</ul>

Currently located in Hangzhou, Zhejiang. This machine arrives ready for demolition prep, site grading, drainage installation, or loader support. Fuel tank holds 250L for extended operation between refills.

Caterpillar 313D

Expand your heavy excavation capacity with this 2020 XCMG XE900D, a 90-ton workhorse engineered for contractors managing multiple jobsites simultaneously. Powered by a robust 399kW engine delivering 480kN of bucket digging force, this Chinese-manufactured excavator integrates seamlessly into existing fleets requiring backup equipment or additional reach during peak demand cycles.

Currently located in Wenzhou, Zhejiang, this backhoe-configured machine offers operational versatility across demolition, mining, and large-scale earthmoving projects. With a maximum digging radius of 12,330mm and depth capacity reaching 7,250mm, it matches the performance envelope of comparable Western units while maintaining lower acquisition costs.

<ul>
<li>Working weight: 89,600kg with 4.1-6.0m³ bucket capacity</li>
<li>Hydraulic performance: 370kN rod digging force, 6.3rpm rotation speed</li>
<li>Mobility: 2.8-4.2km/h travel speed for efficient repositioning</li>
<li>Maximum excavation height: 12,060mm</li>
<li>Traditional diesel power system with proven reliability</li>
</ul>

Ideal for contractors seeking fleet redundancy without capital-intensive new equipment purchases. Ready for immediate deployment on infrastructure or resource ex

XCMG XE900D

Expand your operational capacity with this 2019 Caterpillar 336E hydraulic excavator, a proven 36-ton workhorse engineered for contractors managing multiple jobsites simultaneously. Powered by the Caterpillar C9 ACERT engine delivering 236 kW at 1800 rpm, this machine meets European Stage IIIB and Tier 4 emission standards while maintaining the reliability your fleet demands.

Currently located in Wenzhou, Zhejiang, this excavator provides immediate deployment capability for projects requiring substantial reach and digging force. With an 11,040 mm maximum digging radius and 35,500 kg working weight, it handles deep excavation, loading, and material handling tasks without downtime disruptions to your primary equipment.

<ul>
<li>Joint venture/import quality construction ensures parts availability and service support</li>
<li>Water-cooled engine system maintains consistent performance in demanding conditions</li>
<li>Backhoe bucket configuration ready for trenching and foundation work</li>
<li>Seamless integration with existing Caterpillar fleet management protocols</li>
</ul>

Add redundancy and scheduling flexibility to your operations. Contact Fair Trade Machinery today for complete specifications and acquisition term

Caterpillar 336E

Maximize your equipment budget with this 2016 XCMG XE215 excavator, delivering professional-grade performance at a fraction of new machine costs. Powered by traditional diesel technology, this 21-ton workhorse combines proven reliability with substantial savings for contractors seeking smart capital allocation. Currently located in Hangzhou, Zhejiang, this China-manufactured unit offers immediate deployment capability without the depreciation hit of new equipment.

<ul>
<li>Year: 2016</li>
<li>Model: XCMG XE215</li>
<li>Operating Weight: 21 tons</li>
<li>Power Type: Traditional diesel</li>
<li>Configuration: Backhoe bucket</li>
<li>Origin: Made in China</li>
<li>Location: Hangzhou, Zhejiang</li>
</ul>

Invest in proven excavation capacity without premium pricing. This XE215 represents sound financial strategy for operations requiring dependable mid-size excavation power. Reduce project costs while maintaining productivity standards expected from XCMG engineering.

XCMG XE215

Engineered for precision work in confined spaces, this 2021 XCMG XE35U mini excavator delivers exceptional operator control across 4 tons of working weight. Powered by a reliable 3TNV88-B engine generating 22.2 kW at 2400 rpm, this machine combines responsive hydraulics with stable ground performance. The water-cooled, direct-injection system ensures consistent power delivery during extended shifts.

Operators benefit from superior visibility and intuitive handling thanks to the compact 4970 mm transport length and 1740 mm width. The 9 rpm rotation speed enables smooth positioning, while 36.6 kPa ground pressure minimizes surface disruption on sensitive sites. With a 5300 mm maximum digging radius and 3060 mm digging depth, this excavator handles diverse tasks from trenching to landscaping.

<ul>
<li>Bucket digging force: 28.6 kN for tough soil conditions</li>
<li>Stable travel speed: 3.6/2.2 km/h with 31.6 kN tractive force</li>
<li>108 l/min main pump flow for responsive cycle times</li>
<li>30% climbing ability for sloped terrain access</li>
<li>Currently located in Hangzhou, Zhejiang—ready for global shipment</li>
</ul>

XCMG XE35U

Built for precision and all-day productivity, this 2014 Caterpillar 312D excavator delivers 72 kW of reliable power through its C4.2 ACERT engine. Operating at 12 tons with a 12,920 kg working weight, this mid-size machine combines robust digging performance with exceptional operator comfort. Equipped with a 0.52 m³ backhoe bucket, it generates 96 kN of bucket digging force and reaches a maximum digging depth of 5,840 mm, handling demanding excavation tasks with confidence.

Operator-focused design ensures superior control and reduced fatigue during extended shifts. The spacious cab provides excellent 360-degree visibility, while intuitive hydraulic controls respond precisely to input. Stable performance comes from a 2,590 mm track gauge and 500 mm-wide track plates, maintaining balance on uneven terrain. The 4.12 MPa pilot oil circuit delivers smooth, responsive movements for fine grading and loading operations.

<ul>
<li>Maximum excavation height: 8,580 mm</li>
<li>Maximum reach: 8,430 mm at ground level</li>
<li>Travel speeds: 3.4/5.5 km/h for efficient repositioning</li>
<li>Water-cooled system with 250 L fuel capacity</li>
<li>Currently located in Hangzhou, Zhejiang</li>
</ul>

Caterpillar 312D

Available now in Zhejiang Hangzhou, this 2018 XCMG XE200 hydraulic excavator is ready for immediate deployment to your job site. Skip the factory lead times and get this 20-ton workhorse operating within days, not months. Powered by proven traditional diesel technology, this joint venture-manufactured machine delivers the reliability your project demands without the wait.

<ul>
<li>20-ton operating weight for versatile mid-size applications</li>
<li>Traditional power system ensures straightforward maintenance and fuel availability</li>
<li>Standard backhoe configuration ready for trenching, grading, and material handling</li>
<li>Joint venture manufacturing combines local support with international quality standards</li>
<li>Currently located in Zhejiang Hangzhou for fast logistics throughout East China</li>
</ul>

Reduce your project startup time significantly. This XE200 eliminates procurement delays that plague new equipment orders. Inspect on-site, arrange transport, and begin operations—all while competitors are still waiting for factory allocation. Ideal for contractors who need proven capacity now, not promises later.

XCMG XE200

Built for relentless performance, this 2022 Caterpillar 312D2GC excavator delivers proven reliability in a 12-ton package. Powered by the robust Caterpillar 3054C engine with 59kW rated output and water-cooling efficiency, this machine combines joint venture manufacturing quality with field-tested durability. Operating weight of 12,500kg ensures stability while the 0.53m³ backhoe bucket tackles demanding excavation tasks with 95kN bucket digging force and 65kN rod digging force.

<ul>
<li>Maximum Reach: 8,180mm excavation radius, 5,540mm digging depth</li>
<li>Hydraulic Power: 232 L/min main pump flow, 30.5 MPa working pressure</li>
<li>Boom/Arm Configuration: 4,650mm boom, 2,500mm rod for versatile applications</li>
<li>Mobility: 5.1 km/h travel speed, 2,140mm rear turning radius</li>
<li>Fuel Capacity: 250L tank supports extended operation cycles</li>
<li>Location: Hangzhou, Zhejiang – ready for immediate deployment</li>
</ul>

Manufactured in Xuzhou with Caterpillar's engineering standards, this workhorse represents proven construction-grade equipment with minimal operational hours. Compact 2,490mm transport width facilita

Caterpillar 312D2GC

Investing in a proven workhorse means long-term reliability and peace of mind. This 2017 Caterpillar 336E excavator delivers 236 kW of power from its dependable C9 ACERT engine, backed by Caterpillar's global parts network and legendary resale value. With 36 tons of operating weight and an 11,040 mm maximum digging radius, this machine tackles demanding excavation, demolition, and material handling tasks with precision.

Caterpillar's reputation in the used equipment market remains unmatched. Parts availability is never a concern—genuine CAT components are accessible worldwide, minimizing downtime and protecting your investment. Water-cooled efficiency and compliance with European Stage IIIB/Tier 4 emission standards make this 336E a forward-thinking choice for environmentally conscious operations.

<ul>
<li>Operating Weight: 35,500 kg</li>
<li>Engine: Caterpillar C9 ACERT, 236 kW @ 1,800 RPM</li>
<li>Max Digging Radius: 11,040 mm</li>
<li>Location: Hangzhou, Zhejiang</li>
<li>Configuration: Backhoe bucket</li>
</ul>

Buy with confidence. Caterpillar machines retain value better than competitors, ensuring strong ROI whether you're expanding your fleet or reselling in the future.

Engineered for precision and power, this 2023 Caterpillar 374D excavator delivers 70 tons of reliable performance in demanding mining and quarrying applications. Sourced from Zhejiang, Hangzhou, this joint venture/import machine represents Caterpillar's commitment to operator-centric design and operational efficiency.

Operators benefit from exceptional cabin visibility, enabling confident maneuvering around job sites and enhanced safety during complex digging operations. The advanced suspension seat and climate-controlled environment reduce fatigue during extended shifts, while intuitive hydraulic controls provide responsive handling across all backhoe functions.

<ul>
<li>70-ton operating weight for maximum stability on uneven terrain</li>
<li>Traditional power system ensuring proven reliability and serviceability</li>
<li>Panoramic cab design with minimal blind spots for superior site awareness</li>
<li>Backhoe configuration optimized for deep excavation and material handling</li>
<li>Hydraulically dampened boom for smooth, controlled operation</li>
<li>2023 production year with low operational hours</li>
</ul>

This 374D combines Caterpillar's legendary durability with ergonomic features that prioritize operator co

Caterpillar 374D

Expand your fleet capacity with this 2021 XCMG XE205DA, a proven 20-ton workhorse built for contractors managing multiple job sites. Powered by a robust QSB7 engine delivering 135 kW at 2050 rpm, this excavator handles demanding tasks with 157 kN bucket digging force and a maximum digging depth of 6660 mm. The 5680 mm boom and 2910 mm arm provide a commanding 9760 mm maximum reach, making it ideal for deep excavation, grading, and loading operations.

<ul>
 <li>Working weight: 21,500 kg with 1.0-1.2 m³ bucket capacity</li>
 <li>Water-cooled 6-cylinder engine (6.7 L displacement) ensures reliable performance</li>
 <li>400 L fuel tank supports extended operation between refills</li>
 <li>Travel speed up to 5.7 km/h with 35% climbing ability</li>
 <li>Compact transport dimensions: 9630 mm × 2910 mm × 3100 mm</li>
 <li>12 rpm rotation speed for efficient cycle times</li>
</ul>

Currently located in Jiangsu, China, this machine integrates seamlessly into existing XCMG fleets or serves as dependable backup equipment during peak season. Factory-direct pricing available for immediate deployment.

XCMG XE205DA

Acquire proven excavation power without the premium price tag. This 2016 XCMG XE200 delivers 20-ton performance with traditional diesel reliability, offering exceptional value for contractors seeking cost-effective expansion. Currently located in Jiangsu, this joint venture-manufactured machine combines international engineering standards with practical field capability.

Engineered for demanding applications, the XE200 handles trenching, foundation work, and material handling with confidence. Its backhoe configuration provides versatility across construction and infrastructure projects, while the established 20-ton class ensures compatibility with your existing fleet operations.

<ul>
<li>Year: 2016</li>
<li>Model: XCMG XE200</li>
<li>Operating Weight: 20 tons</li>
<li>Power Type: Traditional diesel</li>
<li>Manufacturing: Joint venture/Import quality</li>
<li>Configuration: Backhoe</li>
<li>Location: Jiangsu, China</li>
</ul>

Invest strategically in reliable machinery that delivers productivity from day one. Contact Fair Trade Machinery for detailed specifications, inspection reports, and competitiv

Engineered with precision hydraulics and a proven Yanmar 4TNV94L engine, this 6-ton mini excavator delivers 39.8 kW of rated power at 2200 rpm. The Rexroth main pump system provides dual 60.5 l/min flow plus auxiliary circuits, ensuring responsive control across all functions. With 42.5 kN bucket digging force and 28.5 kN arm force, this machine tackles demanding excavation tasks with authority.

Compact dimensions of 5850mm transport length and 1880mm width enable operation in confined urban sites, while the 6130mm maximum digging radius and 3830mm digging depth provide impressive reach for its class. The water-cooled 4-cylinder engine with 3.054L displacement maintains consistent performance under load. Standard hydraulic breaker lines expand versatility for demolition work.

<ul>
<li>Working weight: 5960 kg with optimal 32.1 kPa ground pressure</li>
<li>Hydraulic system: 22 MPa main circuit, 23 MPa swing circuit</li>
<li>Travel speed: 4.2/2.2 km/h with 35° climbing capability</li>
<li>Fuel capacity: 110L tank for extended operation</li>
<li>Bucket range: 0.09-0.23 m³ for application flexibility</li>
</ul>

Currently available in Laibin, Guangxi. Manufactured in Xuzhou, China by XCMG.

Specifications	Value
No.	1040140
Tonnage (tons)	50
Working weight (kg)	47300
Bucket capacity (m³)	2.1 ~ 2.5
Boom length (mm)	7060
Rod length (mm)	2900
power	Traditional power
manufacturer	Made in China
bucket	backhoe
Engine type	Cummins QSM11
Rated power (kw/rpm)	250/2100
Maximum torque (N.m/rpm)	1674/1400
Number of cylinders (PCS)	6
Displacement (L)	11
Ground specific pressure (Kpa)	85.9
Rotation speed (rpm)	9
Climbing ability (%)	35
Bucket digging force (kN)	284
Rod digging force (kN)	236
Maximum tractive force (kN)	236
Travel speed (km/h)	5.4/3.2
Maximum flow of main pump (l/min)	2 x 360
Traveling Hydraulic Circuit (Mpa)	34.3
Rotary Hydraulic Circuit (Mpa)	28.4
Pilot Oil Circuit (MPa)	3.9
Fuel Tank (L)	725
Hydraulic Tank (L)	430
Engine Oil changes (L)	38
Total transport length (mm)	12032
Total transport width (mm)	3724
Total transport height (mm)	4165
Counterweight ground clearance (mm)	1360
Minimum ground clearance (mm)	703(without tooth height)
Back end turning radius (mm)	3665
Total track length (mm)	5220
Track gauge (mm)	2392/2890
Total track width (mm)	600
Maximum digging radius (mm)	11631
Maximum digging depth (mm)	7337
Maximum excavation height (mm)	10675
Maximum unloading height (mm)	7409
Maximum vertical digging depth (mm)	5225

2017 XCMG XE500C
