Product Description
Available now in 四川泸州, this 2013 XCMG XE60 mini excavator delivers immediate operational capability without factory wait times. Operating at 6 tons with a working weight of 5,960 kg, this compact machine combines Yanmar 4TNV94L power (39.8 kW at 2200 rpm) with Rexroth hydraulic systems for reliable performance on demanding job sites.
Fast deployment to your site means you can start work immediately. Key specifications include:
- Maximum digging depth: 3,830 mm with 6,130 mm reach
- Bucket digging force: 42.5 kN for tough material handling
- Dual-speed travel: 4.2/2.2 km/h for efficient repositioning
- Compact transport dimensions: 5,850 × 1,880 × 2,585 mm
- 35° climbing ability with 32.1 kPa ground pressure
- Standard hydraulic crushing pipeline included
Skip the factory lead times and secure this Xuzhou-manufactured excavator today. Located in 四川泸州 for immediate pickup or rapid delivery, this water-cooled, 4-cylinder machine offers proven Chinese engineering with bucket capacity ranging from 0.09 to 0.23 m³. Ready for construction, landscaping, and utility applications.
| Specifications | Value |
|---|---|
| No. | 997948 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
