Built for precision work on compact sites, this 7-ton excavator delivers serious digging power where space is limited. With 57 kN bucket digging force and a 6,260 mm maximum reach, it handles trenching, foundation prep, and utility installation with controlled accuracy. The 0.30 m³ bucket moves material efficiently while the 43 kW engine provides consistent hydraulic flow through demanding cycles.
Compact dimensions—6,150 mm transport length and 2,230 mm width—make it maneuverable on congested jobsites and easy to trailer between locations. Dig to 4,020 mm depth for deep utility runs or reach 7,085 mm high for loading trucks and shaping slopes. The V2607 engine delivers 255.8 N·m torque across a broad power band, maintaining performance under load.
Ready to work in Shaoxing, Zhejiang. This machine arrives with full hydraulic systems, 130 L fuel capacity for extended shifts, and proven XCMG engineering. No break-in period required—put it on the trailer and start billing hours.
| Specifications | Value |
|---|---|
| No. | 1021124 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.30 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | v2607 |
| Rated power (kw/rpm) | 43/2000 |
| Maximum torque (N.m) | 255.8/1400-1800 |
| Displacement (L) | 2.6 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.32 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 516 |
| Maximum vertical digging depth (mm) | 2920 |
