Product Description
Built for demanding excavation work, this 2016 Komatsu PC200-8N1 delivers reliable performance across construction and earthmoving applications. Operating at 20 tons with a 19,500 kg working weight, this machine combines power and precision for digging, grading, and material handling tasks. Its Komatsu SAA6D107E-1-A engine generates 110 kW at 2000 rpm, providing consistent hydraulic power through a 34.8 MPa working circuit.
Equipped with a 0.8 m³ backhoe bucket and 2900 mm rod, this excavator reaches a maximum digging depth of 6,620 mm and extends to 9,875 mm digging radius. Bucket digging force measures 149 kN, while rod digging force delivers 108 kN for breaking through compacted material. The water-cooled 6-cylinder engine with 6.69L displacement ensures sustained operation during extended shifts.
- Maximum excavation height: 10,000 mm for loading operations
- Travel speed: 5.5 km/h for efficient site mobility
- 400L fuel capacity supports full-day productivity
- Located in Jiangsu, ready for immediate deployment
This joint venture-manufactured unit stands site-ready with proven Japanese engineering and comprehensive hydraulic systems totaling 232L capacity.
| Specifications | Value |
|---|---|
| No. | 997697 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19500 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2900 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Komatsu SAA6D107E-1-A |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.69 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 44.1 |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 108 |
| Travel speed (km/h) | 5.5/4.1/3.0 |
| Rotary hydraulic motor type | Fixed displacement axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 37.3 |
| Working Hydraulic Circuit (Mpa) | 34.8 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 135 |
| Hydraulic System (L) | 232 |
| Total transport length (mm) | 9425 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3040 |
| Minimum turning radius of front working device (mm) | 3040 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9875 |
| Maximum digging depth (mm) | 6620 |
| Maximum excavation height (mm) | 10000 |
| Maximum unloading height (mm) | 1110 |
| Maximum excavation radius of stop surface (mm) | 9700 |
