Product Description
Engineered for relentless performance, this 2020 Sany SY245H medium excavator delivers proven reliability across demanding job sites. With 147 kW of rated power from its robust D06FRC water-cooled engine and 24-ton operating capacity, this machine handles heavy excavation tasks with consistent efficiency. Its 1.5 m³ bucket capacity and impressive 175 kN bucket digging force tackle tough materials while maintaining operational stability through 53.2 kPa ground pressure distribution.
Built on Sany's reputation for durability, this workhorse features a comprehensive hydraulic system with 277L tank capacity and 475L fuel reservoir for extended work cycles. Maximum digging reach extends to 10,225 mm with 6,705 mm depth capability, providing versatile performance in utility, road construction, and excavation applications. Currently located in Zhejiang, China, this SY245H represents solid value with proven track record and dependable Chinese manufacturing quality.
- 24-ton working weight with 147 kW power output
- 175 kN bucket digging force, 120 kN arm force
- 10,225 mm maximum reach, 6,705 mm dig depth
- Water-cooled 6-cylinder engine (750 N·m torque)
- Ready for immediate deployment from Z
| Specifications | Value |
|---|---|
| No. | 1022608 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
