Product Description
Well-maintained 2020 Sumitomo SH350-5 hydraulic excavator available in Fujian, China. This 35-ton class machine features the proven A5 series design with improved fuel efficiency and operator comfort. Genuine hour meter reading shows approximately 7,000 operating hours, indicating moderate use with significant service life remaining.
Key highlights:
- Original condition with complete maintenance records
- Isuzu engine with advanced emission control
- Responsive hydraulic system for precise operation
- Spacious ROPS/FOPS certified cab
- Suitable for earthmoving, demolition, and general construction
This unit represents excellent value for contractors seeking reliable performance at a competitive price point. The SH350-5 is known for durability and low operating costs in demanding applications. Inspection welcome. Contact us for detailed specifications and delivery arrangements.
| Specifications | Value |
|---|---|
| No. | 1141681 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | AH-6HK1XYSS |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
